ATMEGA644PV-10MQ
RoHS
RoHS compliant
RoHS compliantPackage 44-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 64KB FLASH 44VQFN
PDF
/
Inventory: 6891
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-VFQFN Exposed Pad
Number of Pins 44
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Published 1997
Series AVR? ATmega
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Additional Feature OPERATES AT 1.8 V MIN @ 4 MHZ
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 10MHz
Base Part Number ATMEGA644P
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.7V
Interface 2-Wire, I2C, SPI, UART, USART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 32
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 64KB 32K x 16
Connectivity I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 8x10b
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
EEPROM Size 2K x 8
On Chip Program ROM Width 16
Screening Level TS 16949
Dimensions
Height Seated (Max) 1mm
Length 7mm
Compliance
RoHS Status ROHS3 Compliant
