ATMEGA48P-20MU
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU, 8BIT, AVR, 4K FLASH, 32QFN
PDF
/
Buying Options
Total Price: USD $2.34
Unit Price: USD $2.3408
≥1 USD $2.3408
≥10 USD $2.1472
≥100 USD $1.936
Inventory: 93
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 5.1mm
Length 5.1mm
Height 1mm
Technical
Number of SPI Channels 2
Number of I2C Channels 1
Number of PWM Channels 6
Number of ADC Channels 8
EEPROM Size 256 x 8
Number of Timers/Counters 3
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x10b
Bit Size 8
Supply Current-Max 9mA
Connectivity I2C, SPI, UART/USART
Program Memory Size 4KB 2K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor AVR
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
RAM Size 512 x 8
Number of I/O 23
Oscillator Type Internal
Memory Size 4kB
Interface I2C, SPI, UART, USART
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Base Part Number ATMEGA48P
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series AVR? ATmega
Published 1997
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 32
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
