ATMEGA324A-MCH
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Dual Rows, Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 44QFN
PDF
/
Inventory: 9022
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-VQFN Dual Rows, Exposed Pad
Number of Pins 44
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Published 2008
Series AVR? ATmega
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Terminal Pitch 0.5mm
Frequency 20MHz
Base Part Number ATMEGA324A
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Supply Voltage-Min (Vsup) 1.8V
Interface I2C, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 32
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Connectivity I2C, SPI, UART/USART
Supply Current-Max 12mA
Bit Size 8
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
EEPROM Size 1K x 8
On Chip Program ROM Width 16
Boundary Scan YES
Low Power Mode YES
Format FIXED-POINT
Integrated Cache NO
RAM (words) 2048
Number of Serial I/Os 2
Number of External Interrupts 3
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 1mm
Length 7mm
Compliance
RoHS Status ROHS3 Compliant
