ATMEGA32-16AQR
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU AVR 32KB FLASH 16MHZ 44TQFP
PDF
/
Buying Options
Total Price: USD $55.19
Unit Price: USD $55.18835
≥1 USD $55.18835
≥10 USD $45.2827
≥100 USD $43.86815
≥500 USD $42.45265
≥1000 USD $41.03715
Inventory: 1134
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 44-TQFP
Surface Mount YES
Number of Pins 44
Technical
Operating Temperature -40°C~105°C TA
Packaging Tape & Reel (TR)
Published 2004
Series AVR? ATmega
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Additional Feature Q TEMP GRADE NOT PROVIDED
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 0.8mm
Frequency 16MHz
Base Part Number ATMEGA32
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Interface I2C, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 32
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 16K x 16
Connectivity I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 8x10b
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
EEPROM Size 1K x 8
On Chip Program ROM Width 8
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
RoHS Status ROHS3 Compliant
