ATMEGA2561V-8AUR
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 256KB FLASH 64TQFP
PDF
/
Buying Options
Total Price: USD $13.8
Unit Price: USD $13.7984
≥1 USD $13.7984
≥10 USD $12.6456
≥100 USD $11.457688
Inventory: 6531
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 14mm
Height Seated (Max) 1.2mm
Technical
EEPROM Size 4K x 8
ROM (words) 131072
Address Bus Width 16
Number of Timers/Counters 6
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Data Converter A/D 8x10b
Bit Size 8
Supply Current-Max 14mA
Connectivity EBI/EMI, I2C, SPI, UART/USART
Program Memory Size 256KB 128K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor AVR
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
Memory Type FLASH, OTP
RAM Size 8K x 8
Number of I/O 54
Oscillator Type Internal
Memory Size 32kB
Interface EBI/EMI, I2C, SPI, UART, USART
Supply Voltage-Min (Vsup) 2.7V
Power Supplies 2/5V
Supply Voltage-Max (Vsup) 5.5V
Base Part Number ATMEGA2561
Time@Peak Reflow Temperature-Max (s) 40
Frequency 8MHz
Terminal Pitch 0.8mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Additional Feature ALSO OPERATES AT 1.8V MINIMUM SUPPLY AT 2 MHZ
Terminal Finish Matte Tin (Sn)
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series AVR? ATmega
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 64
Package / Case 64-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
