AT89LP6440-20MU
RoHS
RoHS compliant
RoHS compliantPackage 44-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 64KB FLASH 44VQFN
PDF
/
Buying Options
Total Price: USD $4.45
Unit Price: USD $4.44695
≥1 USD $4.44695
≥10 USD $3.64895
≥100 USD $3.53495
≥500 USD $3.42095
≥1000 USD $3.30695
Inventory: 1525
Minimum: 1
-
+
Technical Details
Technical
Qualification Status Not Qualified
Supply Voltage-Min (Vsup) 2.7V
Interface 2-Wire, I2C, SPI, UART, USART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 38
Speed 24 MHz
RAM Size 4.25K x 8
Voltage - Supply (Vcc/Vdd) 2.4V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor 8051
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 64KB 64K x 8
Connectivity I2C, SPI, UART/USART
Supply Current-Max 8.5mA
Bit Size 8
Data Converter A/D 8x10b
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 3
Address Bus Width 16
EEPROM Size 8K x 8
Base Part Number AT89LP6440
Frequency 20MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Additional Feature OPERATES AT 1.8 V MINIMUM SUPPLY AT 12 MHZ
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 89LP
Published 2011
Packaging Tray
Operating Temperature -40°C~85°C TA
Dimensions
Height Seated (Max) 1mm
Length 7mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Number of Pins 44
Package / Case 44-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
