AT32UC3A0512-ALTT
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 512KB FLASH 144LQFP
PDF
/
Inventory: 2666
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 144-LQFP
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Published 2009
Series AVR?32 UC3 A0
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
Additional Feature IT ALSO OPERATES AT 3.3 V
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Base Part Number AT32UC3A0512
JESD-30 Code S-PQFP-G144
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 1.95V
Power Supplies 1.83.3V
Supply Voltage-Min (Vsup) 1.65V
Oscillator Type Internal
Number of I/O 109
Speed 66MHz
RAM Size 64K x 8
Voltage - Supply (Vcc/Vdd) 1.65V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency 16MHz
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 512KB 512K x 8
Connectivity EBI/EMI, Ethernet, I2C, SPI, SSC, UART/USART, USB OTG
Bit Size 32
Data Converter A/D 8x10b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
Address Bus Width 24
ROM (words) 524288
External Data Bus Width 16
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Width 20mm
Compliance
RoHS Status ROHS3 Compliant
