U8397BH
RoHS
/
Package /
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Buying Options
Total Price: USD $49.77
Unit Price: USD $49.7728
≥1 USD $49.7728
Inventory: 864
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 19.05mm
Length 58mm
Height Seated (Max) 5.65mm
Technical
On Chip Data RAM Width 8
Number of External Interrupts 1
ROM Programmability MROM
Number of Timers 2
Number of Serial I/Os 1
RAM (bytes) 232
RAM (words) 232
Integrated Cache NO
Format FIXED POINT
External Data Bus Width 16
Low Power Mode YES
Boundary Scan NO
CPU Family 8096
On Chip Program ROM Width 8
ROM (words) 8000
Address Bus Width 16
DAC Channels NO
PWM Channels YES
DMA Channels NO
Has ADC YES
Bit Size 16
Supply Current-Max 240mA
Clock Frequency 12MHz
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Speed 12 MHz
Number of I/O 40
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade COMMERCIAL
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T64
Pin Count 64
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.778mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form THROUGH-HOLE
Terminal Position DUAL
Technology NMOS
Subcategory Microcontrollers
HTS Code 8542.31.00.01
Additional Feature FOUR SOFTWARE TIMERS; ROM PROTECT; POWER-DOWN PIN VPD 4.5 - 5.5V
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 64
JESD-609 Code e0
Physical
Surface Mount NO
