TN80C251TB24
RoHS
/
Package PLCC
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MPU 8-BIT 5V 24MHZ EXT 44PLCC
PDF
/
Inventory: 8303
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case PLCC
Surface Mount YES
Technical
Packaging Bulk
Number of Terminations 44
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Supply Voltage 5V
Terminal Pitch 1.27mm
Frequency 24MHz
Pin Count 44
JESD-30 Code S-PQCC-J44
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 4.5V
Oscillator Type External
Number of I/O 32
RAM Size 1kB
Memory Type ROMless
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Peripherals PWM, WDT
Supply Current-Max 83mA
Bit Size 8
Access Time 24 μs
Has ADC NO
DMA Channels NO
PWM Channels YES
DAC Channels NO
Address Bus Width 18
ROM (words) 0
CPU Family 80251
External Data Bus Width 8
RAM (bytes) 1024
Dimensions
Height Seated (Max) 4.57mm
Length 16.5862mm
Width 16.5862mm
Compliance
RoHS Status Non-RoHS Compliant
