N80C196NT
RoHS
/
Package PLCC
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 24.2mm
Length 24.2mm
Height Seated (Max) 4.83mm
Technical
On Chip Data RAM Width 8
Number of External Interrupts 2
Number of Timers 2
Number of Serial I/Os 1
RAM (bytes) 1512
RAM (words) 1000
Integrated Cache NO
Format FIXED POINT
External Data Bus Width 16
Low Power Mode YES
Boundary Scan NO
CPU Family 8096
ROM (words) 0
Address Bus Width 20
DAC Channels NO
PWM Channels YES
DMA Channels NO
Has ADC YES
Access Time 20 μs
Bit Size 16
Supply Current-Max 90mA
Peripherals WDT
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Memory Type ROMless
RAM Size 1.5kB
Number of I/O 56
Oscillator Type External
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade COMMERCIAL
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
JESD-30 Code S-PQCC-J68
Pin Count 68
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 20MHz
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form J BEND
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
HTS Code 8542.31.00.01
Additional Feature 512 X 8 RAM FOR CODE; 1 MBYTE LINEAR ADDRESS SPACE
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 68
JESD-609 Code e0
Packaging Bulk
Physical
Surface Mount YES
Package / Case PLCC
