C167CSL40MCABXUMA2
RoHS
RoHS compliant
RoHS compliantPackage 144-BQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT ROMLESS 144MQFP
PDF
/
Inventory: 3601
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 144-BQFP
Surface Mount YES
Technical
Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Published 2001
Series C16xx
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
ECCN Code 3A991.A.2
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 4.9V
Terminal Pitch 0.65mm
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code S-PQFP-G144
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.5V
Oscillator Type External
Number of I/O 111
Speed 40MHz
RAM Size 11K x 8
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor C166
Peripherals POR, PWM, WDT
Clock Frequency 40MHz
Program Memory Type ROMless
Core Size 16-Bit
Connectivity CANbus, EBI/EMI, SPI, UART/USART
Bit Size 16
Data Converter A/D 24x10b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels NO
Address Bus Width 24
External Data Bus Width 16
RAM (bytes) 11264
Dimensions
Height Seated (Max) 4.1mm
Length 28mm
Width 28mm
Compliance
RoHS Status RoHS Compliant
