B505CA4EMCAXP
RoHS
/
Package /
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 10 BIT OTP 32KBYTE
PDF
/
Buying Options
Total Price: USD $8.61
Unit Price: USD $8.6064
≥1 USD $8.6064
Inventory: 228
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Number of Pins 44
Technical
Number of Terminations 44
Max Operating Temperature 70°C
Min Operating Temperature 0°C
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 0.8mm
Operating Supply Voltage 5V
Temperature Grade INDUSTRIAL
Interface USART
Max Supply Voltage 5.5V
Min Supply Voltage 4.25V
Memory Size 32kB
Power Dissipation-Max 1W
Number of I/O 34
RAM Size 1.3kB
Memory Type EPROM
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Bit Size 8
Frequency (Max) 20MHz
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Address Bus Width 16
ROM (words) 32768
Core Architecture 8051
On Chip Program ROM Width 8
RAM (bytes) 1024
ROM Programmability OTPROM
Dimensions
Height Seated (Max) 2.45mm
Length 10mm
Compliance
RoHS Status RoHS Compliant
