MB96F326RSBPMC-GSE2
RoHS
RoHS compliant
RoHS compliantPackage 80-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
RoHS Compliant Surface Mount FLASH Internal Microcontroller 750mW 125C 56MHz 12K x 8
PDF
/
Inventory: 975
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 80-LQFP
Number of Pins 80
Supplier Device Package 80-LQFP (12x12)
Technical
Operating Temperature -40°C~125°C TA
Packaging Tray
Published 2008
Series F2MC-16FX MB96320
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Max Power Dissipation 750mW
Frequency 56MHz
Interface CAN, EBI/EMI, I2C, LIN, SCI, UART, USART
Max Supply Voltage 5.5V
Min Supply Voltage 3V
Memory Size 288kB
Oscillator Type Internal
Number of I/O 66
Speed 56MHz
RAM Size 12K x 8
Memory Type FLASH
Voltage - Supply (Vcc/Vdd) 3V~5.5V
Core Processor F2MC-16FX
Peripherals DMA, LVD, LVR, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 288KB 288K x 8
Connectivity CANbus, EBI/EMI, I2C, LINbus, SCI, UART/USART
Data Converter A/D 18x10b
Watchdog Timer Yes
Data Bus Width 16b
Number of Timers/Counters 3
Max Frequency 56MHz
Number of Programmable I/O 66
Number of ADC Channels 18
Number of PWM Channels 20
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
