RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: 7175
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case SOIC
Surface Mount YES

Technical

JESD-609 Code e0
Number of Terminations 8
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 2.7V
Terminal Pitch 1.27mm
Frequency 4MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
Qualification Status Not Qualified
Temperature Grade COMMERCIAL
Max Supply Voltage 5.5V
Min Supply Voltage 2.2V
Memory Size 2kB
Number of I/O 6
Speed 1 MHz
RAM Size 64B
Memory Type EEPROM
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Supply Current-Max 2mA
Bit Size 8
Frequency (Max) 4MHz
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
CPU Family ACE1202
Number of Programmable I/O 8
RAM (bytes) 64

Dimensions

Height Seated (Max) 1.75mm
Length 4.9mm

Compliance

RoHS Status RoHS Compliant
