RFPIC12F675F-I/SS
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers - Application Specific
Description
IC MCU 1KX14 RF FSK/ASK 20SSOP
PDF
/
Buying Options
Total Price: USD $70
Unit Price: USD $7
≥10 USD $7
Inventory: 18
Minimum: 10
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 5.38mm
Length 7.34mm
Height 1.83mm
Technical
Controller Series rfPIC?
Current - Transmitting 14mA
Number of ADC Channels 4
CPU Family PIC
Number of Timers/Counters 2
PWM Channels NO
Data Bus Width 8b
Data Rate 40 kbps
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Bit Size 8
Program Memory Type FLASH (1.75kB)
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Memory Type FLASH
RAM Size 64 x 8
Number of I/O 6
Memory Size 1.8kB
Interface USB
Operating Supply Voltage 5V
Pin Count 20
Base Part Number RFPIC12F675F
Time@Peak Reflow Temperature-Max (s) 40
Frequency 450MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~5.5V
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
Applications RKE, Security Systems
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC?
Published 2003
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 20
Package / Case 20-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
