MAXQ1004-B01+
RoHS
RoHS compliant
RoHS compliantPackage 16-WQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers - Application Specific
Description
16-bit Microcontrollers - MCU 1-Wire and SPI Authentication MCU
PDF
/
Buying Options
Total Price: USD $5.48
Unit Price: USD $5.475594
≥1 USD $5.475594
≥10 USD $5.165661
≥100 USD $4.873264
≥500 USD $4.59742
≥1000 USD $4.337186
Inventory: 1108
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-WQFN Exposed Pad
Number of Pins 16
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish Matte Tin (Sn)
Applications Authentication
Subcategory Microcontrollers
Max Power Dissipation 2W
Technology CMOS
Voltage - Supply 1.7V~3.6V
Terminal Position QUAD
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Base Part Number MAXQ1004
Pin Count 16
Operating Supply Voltage 3.6V
Interface 1-Wire?, SPI
Memory Size 16kB
Number of I/O 8
RAM Size 640 x 8
Memory Type FLASH, ROM
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MAXQ20
Program Memory Type FLASH (16kB), ROM (4kB)
Supply Current-Max 3.5mA
Bit Size 16
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 16b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 1
Max Frequency 6MHz
Controller Series MAXQ?
Dimensions
Length 4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
