CY8CLED04-68LTXI
RoHS
RoHS compliant
RoHS compliantPackage 68-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers - Application Specific
Description
LED DRVR 3.3V/5V 68-Pin QFN EP
PDF
/
Buying Options
Total Price: USD $4.71
Unit Price: USD $4.708
≥1 USD $4.708
Inventory: 505
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 8mm
Length 8mm
Height 1mm
Technical
Controller Series CY8CLED
Data Input Mode SERIAL
Multiplexed Display Capability NO
Number of Segments 4
fmax-Min 12.96 MHz
Data Bus Width 8b
Program Memory Type FLASH (16KB)
Peripherals LVD, POR, PWM, WDT
Core Processor M8C
Memory Type FLASH
RAM Size 1K x 8
Nominal Supply Current 27mA
Number of I/O 56
Oscillator Type Internal
Operating Supply Current 27mA
Memory Size 16kB
Interface I2C, SPI, UART/USART, USB
Power Supplies 3.3/5V
Pin Count 68
Base Part Number CY8CLED04
Frequency 24MHz
Terminal Pitch 0.4mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Position QUAD
Voltage - Supply 3V~5.25V
Technology CMOS
Subcategory Display Drivers
HTS Code 8542.31.00.01
Additional Feature IT CAN ALSO OPERATES WITH 5 VOLTS
Applications HB LED Controller
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 68
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Series EZ-Color? CY8CLED
Published 2009
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Weight 810.002575mg
Number of Pins 68
Package / Case 68-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
