CY8C20247S-24LKXIT
RoHS
RoHS compliant
RoHS compliantPackage 16-UFQFN
Category Integrated Circuits (ICs) / Embedded - Microcontrollers - Application Specific
Description
8-bit Microcontrollers - MCU 1.8V CapSense Ctrl W/SmartSense
PDF
/
Buying Options
Total Price: USD $0.29
Unit Price: USD $0.290374
≥1 USD $0.290374
≥200 USD $0.112371
≥500 USD $0.108432
≥1000 USD $0.106476
Inventory: 1181
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-UFQFN
Surface Mount YES
Number of Pins 16
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2003
Series CapSense? Controllers
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications Capacitive Sensing
Subcategory Microcontrollers
Controller Series CY8C20xx7/S
RAM (bytes) 2048
Number of Programmable I/O 13
Max Frequency 24MHz
CPU Family M8C
Number of Timers/Counters 3
Data Bus Width 8b
Watchdog Timer Yes
Bit Size 8
Supply Current-Max 4mA
Program Memory Type FLASH (16kB)
Core Processor M8C
uPs/uCs/Peripheral ICs Type MICROPROCESSOR CIRCUIT
Memory Type FLASH
RAM Size 2K x 8
Speed 25.2 MHz
Memory Size 16kB
Interface I2C, SPI
Power Supplies 1.8/5V
Qualification Status Not Qualified
Pin Count 16
Time@Peak Reflow Temperature-Max (s) 20
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 1.71V~5.5V
Technology CMOS
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.6mm
