CY7C66113C-LTXCT
RoHS
RoHS compliant
RoHS compliantPackage 56-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers - Application Specific
Description
IC MCU 8K USB HUB 4PORT 56VQFN
PDF
/
Buying Options
Total Price: USD $18.82
Unit Price: USD $18.821806
≥1 USD $18.821806
≥10 USD $17.756427
≥100 USD $16.751341
≥500 USD $15.803156
≥1000 USD $14.908628
Inventory: 1474
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 8mm
Height Seated (Max) 1mm
Technical
Controller Series USB Hub
Core Architecture 8051
ROM (words) 8192
DAC Channels YES
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC NO
Bit Size 8
Supply Current-Max 50mA
Program Memory Type OTP (8kB)
Clock Frequency 6MHz
Core Processor M8
Memory Type OTP
RAM Size 256 x 8
Speed 12 MHz
Number of I/O 31
Interface I2C, USB, HAPI
Power Supplies 5V
Pin Count 56
Base Part Number CY7C66113
Terminal Pitch 0.5mm
Supply Voltage 5V
Terminal Position QUAD
Voltage - Supply 4V~5.25V
Technology CMOS
Subcategory Microcontrollers
Applications USB Hub/Microcontroller
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 56
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e3
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 56
Package / Case 56-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
