CY7C63723-SC
RoHS
/
Package 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers - Application Specific
Description
IC MCU 8K LS USB/PS-2 18-SOIC
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.160824
≥1 USD $0.160824
≥10 USD $0.151723
≥100 USD $0.143129
≥500 USD $0.13502
≥1000 USD $0.127384
Inventory: 1450
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 18-SOIC (0.295, 7.50mm Width)
Number of Pins 18
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 1997
Series enCoRe?
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 18
Terminal Finish Tin/Lead (Sn/Pb)
Applications USB Microcontroller
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Voltage - Supply 4V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 225
Supply Voltage 5V
Terminal Pitch 1.27mm
Reach Compliance Code not_compliant
Frequency 12MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number CY7C63723
Pin Count 18
Qualification Status Not Qualified
Power Supplies 5V
Interface PS/2, USB
Number of I/O 10
RAM Size 256 x 8
Memory Type OTP
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor M8B
Program Memory Type OTP (8kB)
Supply Current-Max 20mA
Bit Size 8
Access Time 12 μs
Has ADC NO
DMA Channels NO
PWM Channels NO
DAC Channels NO
ROM (words) 8192
Core Architecture M8C
Controller Series CY7C637xx
Dimensions
Height Seated (Max) 2.667mm
Length 11.5565mm
Width 7.5055mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
