XC3S100E-4CPG132CS1
RoHS
/
Package BGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
CMOS OTHER 2008 RoHS Compliant field programmable gate array 85C 9kB 0.76ns 572MHz
PDF
/
Buying Options
Total Price: USD $122.64
Unit Price: USD $122.641986
≥1 USD $122.641986
≥10 USD $115.699981
≥100 USD $109.150921
≥500 USD $102.972568
≥1000 USD $97.143936
Inventory: 7011
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 8mm
Length 8mm
Height Seated (Max) 1.1mm
Technical
Number of Equivalent Gates 100000
Number of Logic Cells 2160
Number of CLBs 240
Combinatorial Delay of a CLB-Max 0.76 ns
Number of Registers 1920
Speed Grade 4
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Clock Frequency 572MHz
RAM Size 9kB
Temperature Grade OTHER
Power Supplies 1.21.2/3.32.5V
Supply Voltage-Max (Vsup) 1.26V
Operating Supply Voltage 1.2V
Number of Outputs 72
Terminal Pitch 0.5mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Field Programmable Gate Arrays
Min Operating Temperature 0°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 132
Moisture Sensitivity Level (MSL) 3
Pbfree Code yes
JESD-609 Code e1
Published 2008
Physical
Number of Pins 132
Surface Mount YES
Package / Case BGA
