XCV400-4BG560I
RoHS
/
Package 560-LBGA Exposed Pad, Metal
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Virtex? XCV400 560-LBGA Exposed Pad Metal Tin/Lead (Sn63Pb37) field programmable gate array 1.7mm 2.5V 250MHz 0.8ns
PDF
/
Buying Options
Total Price: USD $29.37
Unit Price: USD $29.37495
≥1 USD $29.37495
≥10 USD $24.10245
≥100 USD $23.3491
≥500 USD $22.59575
≥1000 USD $21.8424
Inventory: 1288
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 1.7mm
Technical
Combinatorial Delay of a CLB-Max 0.8 ns
Speed Grade 4
Number of LABs/CLBs 2400
Number of Gates 468252
Total RAM Bits 81920
Number of Logic Elements/Cells 10800
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Inputs 404
Clock Frequency 250MHz
RAM Size 10kB
Number of I/O 404
Operating Supply Voltage 2.5V
Number of Outputs 404
JESD-30 Code S-PBGA-B560
Pin Count 560
Base Part Number XCV400
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 2.5V
Peak Reflow Temperature (Cel) 225
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 2.375V~2.625V
Technology CMOS
Subcategory Field Programmable Gate Arrays
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code 3A991.D
Number of Terminations 560
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series Virtex?
Published 2000
Packaging Tray
Operating Temperature -40°C~100°C TJ
Physical
Package / Case 560-LBGA Exposed Pad, Metal
Mounting Type Surface Mount
Mount Surface Mount
