XCV1600E-7FG680I
RoHS
/
Package 680-LBGA Exposed Pad
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Virtex?-E XCV1600E 680-LBGA Exposed Pad Surface Mount field programmable gate array 1.9mm 1.8V 400MHz 0.42ns
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6093
≥1 USD $1.6093
≥10 USD $1.3205
≥100 USD $1.27965
≥500 USD $1.23785
≥1000 USD $1.197
Inventory: 1100
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 40mm
Length 40mm
Height Seated (Max) 1.9mm
Technical
Number of Equivalent Gates 419904
Combinatorial Delay of a CLB-Max 0.42 ns
Speed Grade 7
Number of LABs/CLBs 7776
Number of Gates 2188742
Total RAM Bits 589824
Number of Logic Elements/Cells 34992
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Inputs 512
Clock Frequency 400MHz
RAM Size 72kB
Number of I/O 512
Operating Supply Voltage 1.8V
Number of Outputs 512
JESD-30 Code S-PBGA-B680
Pin Count 680
Base Part Number XCV1600E
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 225
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.71V~1.89V
Technology CMOS
Subcategory Field Programmable Gate Arrays
HTS Code 8542.39.00.01
ECCN Code EAR99
Number of Terminations 680
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series Virtex?-E
Published 2004
Packaging Tray
Operating Temperature -40°C~100°C TJ
Physical
Package / Case 680-LBGA Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
