XCV100E-7CS144I
RoHS
/
Package 144-TFBGA, CSPBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Virtex?-E XCV100E 144-TFBGA CSPBGA Surface Mount field programmable gate array 1.2mm 1.8V 400MHz 0.42ns
PDF
/
Inventory: 3696
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 144-TFBGA, CSPBGA
Number of Pins 144
Technical
Operating Temperature -40°C~100°C TJ
Packaging Tray
Published 1999
Series Virtex?-E
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
ECCN Code EAR99
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Voltage - Supply 1.71V~1.89V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 240
Supply Voltage 1.8V
Terminal Pitch 0.8mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number XCV100E
Pin Count 144
Number of Outputs 94
Operating Supply Voltage 1.8V
Number of I/O 94
RAM Size 10kB
Clock Frequency 400MHz
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 2700
Total RAM Bits 81920
Number of Gates 128236
Number of LABs/CLBs 600
Speed Grade 7
Combinatorial Delay of a CLB-Max 0.42 ns
Number of CLBs 600
Number of Equivalent Gates 32400
Dimensions
Height Seated (Max) 1.2mm
Length 12mm
Width 12mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
