XCV1000-5FG680I
RoHS
/
Package 680-LBGA Exposed Pad
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Virtex? XCV1000 680-LBGA Exposed Pad Tin/Lead (Sn63Pb37) field programmable gate array 1.7mm 1.2/3.62.5V 294MHz 0.7ns
PDF
/
Inventory: 7790
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 40mm
Length 40mm
Height Seated (Max) 1.7mm
Technical
Combinatorial Delay of a CLB-Max 0.7 ns
Number of LABs/CLBs 6144
Number of Gates 1124022
Total RAM Bits 131072
Number of Logic Elements/Cells 27648
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Inputs 512
Clock Frequency 294MHz
RAM Size 16kB
Number of I/O 512
Power Supplies 1.2/3.62.5V
Qualification Status Not Qualified
Number of Outputs 512
JESD-30 Code S-PBGA-B680
Pin Count 680
Base Part Number XCV1000
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 1mm
Supply Voltage 2.5V
Peak Reflow Temperature (Cel) 225
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 2.375V~2.625V
Technology CMOS
Subcategory Field Programmable Gate Arrays
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code EAR99
Number of Terminations 680
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e0
Series Virtex?
Published 2000
Packaging Tray
Operating Temperature -40°C~100°C TJ
Physical
Package / Case 680-LBGA Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
