XC6VSX315T-2FFG1156C
RoHS
RoHS compliant
RoHS compliantPackage 1156-BBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Virtex?-6SXT XC6VSX315T 1156-BBGA FCBGA Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5) field programmable gate array 3.5mm 1V 3.1MB 0C~85C TJ
PDF
/
Buying Options
Total Price: USD $1065.86
Unit Price: USD $1065.85572
≥1 USD $1065.85572
≥10 USD $1030.808238
≥25 USD $1023.642737
≥50 USD $1016.527047
≥100 USD $995.619055
≥500 USD $924.43737
Inventory: 1664
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 35mm
Length 35mm
Height Seated (Max) 3.5mm
Technical
Speed Grade 2
Number of LABs/CLBs 24600
Total RAM Bits 25952256
Number of Logic Elements/Cells 314880
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
RAM Size 3.1MB
Number of I/O 600
Qualification Status Not Qualified
Number of Outputs 600
Base Part Number XC6VSX315T
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 1mm
Supply Voltage 1V
Peak Reflow Temperature (Cel) 245
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 0.95V~1.05V
Technology CMOS
Subcategory Field Programmable Gate Arrays
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
ECCN Code 3A991.D
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Series Virtex?-6 SXT
Published 2008
Packaging Tray
Operating Temperature 0°C~85°C TJ
Physical
Number of Pins 1156
Package / Case 1156-BBGA, FCBGA
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Copper, Silver, Tin
Supply Chain
Factory Lead Time 10 Weeks
