XC4020E-4HQ208C
RoHS
/
Package 208-BFQFP Exposed Pad
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
XC4000E/X XC4020E 208-BFQFP Exposed Pad Tin/Lead (Sn85Pb15) field programmable gate array 4.1mm 5V 111MHz 2.7ns
PDF
/
Buying Options
Total Price: USD $13.41
Unit Price: USD $13.4102
≥1 USD $13.4102
≥10 USD $11.00385
≥100 USD $10.65995
≥500 USD $10.31605
≥1000 USD $9.97215
Inventory: 1631
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 28mm
Length 28mm
Height Seated (Max) 4.1mm
Technical
Number of Equivalent Gates 13000
Number of Logic Cells 784
Number of CLBs 784
Combinatorial Delay of a CLB-Max 2.7 ns
Number of LABs/CLBs 784
Number of Gates 20000
Total RAM Bits 25088
Number of Logic Elements/Cells 1862
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Inputs 224
Clock Frequency 111MHz
Number of I/O 160
Power Supplies 5V
Qualification Status Not Qualified
Number of Outputs 224
JESD-30 Code S-PQFP-G208
Pin Count 208
Base Part Number XC4020E
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 225
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 4.75V~5.25V
Technology CMOS
Subcategory Field Programmable Gate Arrays
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn85Pb15)
Number of Terminations 208
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series XC4000E/X
Published 1999
Packaging Tray
Operating Temperature 0°C~85°C TJ
Physical
Surface Mount YES
Package / Case 208-BFQFP Exposed Pad
Mounting Type Surface Mount
