XC4013E-2HQ208C
RoHS
/
Package 208-BFQFP Exposed Pad
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
XC4000E/X XC4013E 208-BFQFP Exposed Pad Tin/Lead (Sn85Pb15) field programmable gate array 4.1mm 5V 1.6ns 2.3kB
PDF
/
Inventory: 5590
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 208-BFQFP Exposed Pad
Number of Pins 208
Technical
Operating Temperature 0°C~85°C TJ
Packaging Tray
Published 1999
Series XC4000E/X
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 208
Terminal Finish Tin/Lead (Sn85Pb15)
Subcategory Field Programmable Gate Arrays
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 225
Supply Voltage 5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number XC4013E
Pin Count 208
Number of Outputs 192
Operating Supply Voltage 5V
Power Supplies 5V
Number of I/O 160
RAM Size 2.3kB
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 1368
Total RAM Bits 18432
Number of Gates 13000
Number of LABs/CLBs 576
Speed Grade 2
Number of Registers 1536
Combinatorial Delay of a CLB-Max 1.6 ns
Number of CLBs 576
Number of Logic Cells 576
Number of Equivalent Gates 10000
Dimensions
Height Seated (Max) 4.1mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
