XC4010E-1HQ208C
RoHS
/
Package 208-BFQFP Exposed Pad
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
XC4000E/X XC4010E 208-BFQFP Exposed Pad Surface Mount field programmable gate array 28mm 5V 1.6kB 0C~85C TJ
PDF
/
Inventory: 8672
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 28mm
Length 28mm
Technical
Number of Equivalent Gates 7000
Number of Logic Cells 400
Number of CLBs 400
Number of Registers 1120
Speed Grade 1
Number of LABs/CLBs 400
Number of Gates 10000
Total RAM Bits 12800
Number of Logic Elements/Cells 950
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
RAM Size 1.6kB
Number of I/O 160
Power Supplies 5V
Operating Supply Voltage 5V
Number of Outputs 160
Pin Count 208
Base Part Number XC4010E
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 225
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 4.75V~5.25V
Technology CMOS
Subcategory Field Programmable Gate Arrays
Number of Terminations 208
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series XC4000E/X
Published 1999
Packaging Tray
Operating Temperature 0°C~85°C TJ
Physical
Number of Pins 208
Package / Case 208-BFQFP Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
