XC4005XL-2PC84I

Xilinx Inc.
RoHS
/
Package 84-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description XC4000E/X XC4005XL 84-LCC (J-Lead) Tin/Lead (Sn85Pb15) field programmable gate array 5.08mm 3.3V 179MHz 1.5ns
PDF
/
Inventory: 7823
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 84-LCC (J-Lead)

Technical

Operating Temperature -40°C~100°C TJ
Packaging Tray
Published 1999
Series XC4000E/X
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 84
Terminal Finish Tin/Lead (Sn85Pb15)
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 225
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number XC4005XL
Pin Count 84
JESD-30 Code S-PQCC-J84
Number of Outputs 112
Qualification Status Not Qualified
Power Supplies 3.3V
Number of I/O 61
RAM Size 784B
Clock Frequency 179MHz
Number of Inputs 112
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 466
Total RAM Bits 6272
Number of Gates 5000
Number of LABs/CLBs 196
Combinatorial Delay of a CLB-Max 1.5 ns
Number of CLBs 196
Number of Logic Cells 196
Number of Equivalent Gates 3000

Dimensions

Height Seated (Max) 5.08mm
Length 29.3116mm
Width 29.3116mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
