XC4005XL-09PC84C
RoHS
/
Package 84-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
XC4000E/X XC4005XL 84-LCC (J-Lead) Tin/Lead (Sn85Pb15) field programmable gate array 5.08mm 3.3V 217MHz 1.2ns
PDF
/
Buying Options
Total Price: USD $13.41
Unit Price: USD $13.4102
≥1 USD $13.4102
≥10 USD $11.00385
≥100 USD $10.65995
≥500 USD $10.31605
≥1000 USD $9.97215
Inventory: 1629
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 84-LCC (J-Lead)
Technical
Operating Temperature 0°C~85°C TJ
Packaging Tray
Published 1999
Series XC4000E/X
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 84
Terminal Finish Tin/Lead (Sn85Pb15)
Additional Feature TYPICAL GATES = 3000-9000
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 225
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number XC4005XL
Pin Count 84
JESD-30 Code S-PQCC-J84
Number of Outputs 112
Qualification Status Not Qualified
Power Supplies 3.3V
Number of I/O 61
RAM Size 784B
Clock Frequency 217MHz
Number of Inputs 112
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 466
Total RAM Bits 6272
Number of Gates 5000
Number of LABs/CLBs 196
Combinatorial Delay of a CLB-Max 1.2 ns
Number of CLBs 196
Number of Logic Cells 196
Number of Equivalent Gates 3000
Dimensions
Height Seated (Max) 5.08mm
Length 29.3116mm
Width 29.3116mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
