XC4005E-4PG156I
RoHS
/
Package 156-BCPGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Contains Lead CMOS 1999 Non-RoHS Compliant field programmable gate array -40C~100C TJ 784B 2.7ns 111MHz
PDF
/
Inventory: 9258
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
Number of Equivalent Gates 3000
Number of Logic Cells 196
Number of CLBs 196
Combinatorial Delay of a CLB-Max 2.7 ns
Number of Registers 616
Speed Grade 4
Number of LABs/CLBs 196
Number of Gates 5000
Total RAM Bits 6272
Number of Logic Elements/Cells 466
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Clock Frequency 111MHz
RAM Size 784B
Number of I/O 112
Power Supplies 5V
Operating Supply Voltage 5V
Number of Outputs 112
Pin Count 156
Base Part Number XC4005E
Supply Voltage 5V
Terminal Form PIN/PEG
Terminal Position PERPENDICULAR
Voltage - Supply 4.5V~5.5V
Technology CMOS
Subcategory Field Programmable Gate Arrays
ECCN Code EAR99
Number of Terminations 156
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series XC4000E/X
Published 1999
Packaging Tray
Operating Temperature -40°C~100°C TJ
Physical
Number of Pins 156
Package / Case 156-BCPGA
Mounting Type Through Hole
Mount Through Hole
