XC3S700A-4FTG256C
RoHS
RoHS compliant
RoHS compliantPackage 256-LBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Spartan?-3A XC3S700A 256-LBGA Surface Mount field programmable gate array 1mm 1.2V 667MHz 0.71ns
PDF
/
Buying Options
Total Price: USD $239.57
Unit Price: USD $239.5653
≥1 USD $239.5653
≥10 USD $214.78265
Inventory: 307
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 17mm
Length 17mm
Height 1mm
Technical
Combinatorial Delay of a CLB-Max 0.71 ns
Speed Grade 4
Number of LABs/CLBs 1472
Number of Gates 700000
Total RAM Bits 368640
Number of Logic Elements/Cells 13248
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Clock Frequency 667MHz
RAM Size 45kB
Number of I/O 161
Power Supplies 1.21.2/3.33.3V
Operating Supply Voltage 1.2V
Qualification Status Not Qualified
Number of Outputs 148
Pin Count 256
Base Part Number XC3S700A
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.14V~1.26V
Technology CMOS
Subcategory Field Programmable Gate Arrays
ECCN Code EAR99
Number of Terminations 256
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e1
Series Spartan?-3A
Published 1999
Packaging Tray
Operating Temperature 0°C~85°C TJ
Physical
Number of Pins 256
Package / Case 256-LBGA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
