XC3S250E-4TQG144C

Xilinx Inc.
RoHS
RoHS RoHS compliant
Package 144-LQFP
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description Spartan?-3E XC3S250E 144-LQFP Matte Tin (Sn) field programmable gate array 1.6mm 1.2V 572MHz 0.76ns
PDF
/
Buying Options
Total Price: USD $58.41
Unit Price: USD $58.4079
≥1 USD $58.4079
≥10 USD $47.92465
≥100 USD $46.4265
≥500 USD $44.9293
≥1000 USD $43.43115
≥3000 USD $38.9386
Inventory: 3804
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 20mm
Length 20mm
Height Seated (Max) 1.6mm

Technical

Number of CLBs 612
Combinatorial Delay of a CLB-Max 0.76 ns
Number of Registers 4896
Speed Grade 4
Number of LABs/CLBs 612
Number of Gates 250000
Total RAM Bits 221184
Number of Logic Elements/Cells 5508
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Clock Frequency 572MHz
RAM Size 27kB
Number of I/O 108
Power Supplies 1.21.2/3.32.5V
Operating Supply Voltage 1.2V
Qualification Status Not Qualified
Number of Outputs 80
Pin Count 144
Base Part Number XC3S250E
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 1.14V~1.26V
Technology CMOS
Subcategory Field Programmable Gate Arrays
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 144
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Spartan?-3E
Published 2008
Packaging Tray
Operating Temperature 0°C~85°C TJ

Physical

Number of Pins 144
Package / Case 144-LQFP
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 10 Weeks
