XC3S1400AN-4FG676I
RoHS
/
Package 676-BBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
CMOS 2007 Non-RoHS Compliant BALL FPGA -40C~100C TJ 72kB 0.71ns 667MHz
PDF
/
Buying Options
Total Price: USD $273.53
Unit Price: USD $273.531588
≥1 USD $273.531588
≥10 USD $258.048662
≥100 USD $243.442147
≥500 USD $229.662398
≥1000 USD $216.662634
Inventory: 1463
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 27mm
Length 27mm
Technical
Combinatorial Delay of a CLB-Max 0.71 ns
Speed Grade 4
Number of LABs/CLBs 2816
Number of Gates 1400000
Total RAM Bits 589824
Number of Logic Elements/Cells 25344
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Clock Frequency 667MHz
RAM Size 72kB
Number of I/O 502
Power Supplies 1.21.2/3.33.3V
Operating Supply Voltage 1.2V
Qualification Status Not Qualified
Number of Outputs 408
Pin Count 676
Base Part Number XC3S1400AN
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 1mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 225
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.14V~1.26V
Technology CMOS
Subcategory Field Programmable Gate Arrays
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code 3A991.D
Number of Terminations 676
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Series Spartan?-3AN
Published 2007
Packaging Tray
Operating Temperature -40°C~100°C TJ
Physical
Number of Pins 676
Package / Case 676-BBGA, FCBGA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
