XC3030-100PC68C
RoHS
/
Package 68-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
XC3000 XC3030 68-LCC (J-Lead) TIN LEAD field programmable gate array 4.445mm 5V 7ns 2.7kB
PDF
/
Buying Options
Total Price: USD $12.08
Unit Price: USD $12.0821
≥1 USD $12.0821
≥10 USD $9.91325
≥100 USD $9.60355
≥500 USD $9.29385
≥1000 USD $8.98415
Inventory: 114
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 68-LCC (J-Lead)
Number of Pins 68
Technical
Operating Temperature 0°C~85°C TJ
Packaging Tray
Published 1995
Series XC3000
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 68
ECCN Code EAR99
Terminal Finish TIN LEAD
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 225
Supply Voltage 5V
Terminal Pitch 1.27mm
Base Part Number XC3030
Pin Count 68
Number of Outputs 58
Operating Supply Voltage 5V
Power Supplies 5V
Number of I/O 58
RAM Size 2.7kB
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Total RAM Bits 22176
Number of Gates 2000
Number of LABs/CLBs 100
Number of Registers 360
Combinatorial Delay of a CLB-Max 7 ns
Number of CLBs 100
Number of Logic Cells 100
Number of Equivalent Gates 1500
Dimensions
Height Seated (Max) 4.445mm
Length 24.2316mm
Width 24.2316mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
