XC2VP20-6FFG896C
RoHS
RoHS compliant
RoHS compliantPackage 896-BBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Virtex?-II Pro XC2VP20 896-BBGA FCBGA Tin/Silver/Copper (Sn95.5Ag4.0Cu0.5) field programmable gate array 3.4mm 1.5V 1200MHz 0.32ns
PDF
/
Buying Options
Total Price: USD $154.2
Unit Price: USD $154.1983
≥1 USD $154.1983
≥10 USD $149.05785
≥100 USD $133.6384
Inventory: 57
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 896-BBGA, FCBGA
Number of Pins 896
Technical
Operating Temperature 0°C~85°C TJ
Packaging Tray
Published 2005
Series Virtex?-II Pro
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 896
ECCN Code 3A991.D
Terminal Finish Tin/Silver/Copper (Sn95.5Ag4.0Cu0.5)
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Voltage - Supply 1.425V~1.575V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 245
Supply Voltage 1.5V
Terminal Pitch 1mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number XC2VP20
Pin Count 896
Number of Outputs 556
Qualification Status Not Qualified
Operating Supply Voltage 1.5V
Power Supplies 1.51.5/3.32/2.52.5V
Number of I/O 556
RAM Size 198kB
Clock Frequency 1200MHz
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 20880
Total RAM Bits 1622016
Number of LABs/CLBs 2320
Speed Grade 6
Number of Registers 18560
Combinatorial Delay of a CLB-Max 0.32 ns
Dimensions
Height Seated (Max) 3.4mm
Length 31mm
Width 31mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
