XC2S30-6VQG100C
RoHS
RoHS compliant
RoHS compliantPackage 100-TQFP
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Spartan?-II 100-TQFP Matte Tin (Sn) Surface Mount field programmable gate array 1.2mm 2.5V 3kB 0C~85C TJ
PDF
/
Inventory: 3775
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Supply Voltage 2.5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 2.375V~2.625V
Subcategory Field Programmable Gate Arrays
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Spartan?-II
Published 2008
Packaging Tray
Operating Temperature 0°C~85°C TJ
Number of Logic Cells 972
Number of CLBs 216
Speed Grade 6
Number of LABs/CLBs 216
Number of Gates 30000
Total RAM Bits 24576
Number of Logic Elements/Cells 972
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
RAM Size 3kB
Number of I/O 60
Operating Supply Voltage 2.5V
Qualification Status Not Qualified
Number of Outputs 92
Pin Count 100
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Physical
Number of Pins 100
Package / Case 100-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 14mm
Length 14mm
Height Seated (Max) 1.2mm
