XC2S150-5FGG456I
RoHS
RoHS compliant
RoHS compliantPackage 456-BBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Spartan?-II 456-BBGA Surface Mount FIELD PROGRAMMABLE GATE ARRAY field programmable gate array 2.6mm 2.5V 263MHz 0.7ns
PDF
/
Buying Options
Total Price: USD $25.71
Unit Price: USD $25.7146
≥1 USD $25.7146
≥10 USD $21.09855
≥100 USD $20.43925
≥500 USD $19.77995
≥1000 USD $19.12065
Inventory: 1148
Minimum: 1
-
+
Technical Details
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 456
ECCN Code 3A991.D
Subcategory Field Programmable Gate Arrays
Voltage - Supply 2.375V~2.625V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 250
Supply Voltage 2.5V
Terminal Pitch 1mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 456
Number of Outputs 260
Qualification Status Not Qualified
Operating Supply Voltage 2.5V
Number of I/O 260
RAM Size 6kB
Clock Frequency 263MHz
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 3888
Total RAM Bits 49152
Number of Gates 150000
Number of LABs/CLBs 864
Speed Grade 5
Combinatorial Delay of a CLB-Max 0.7 ns
Number of CLBs 864
Pbfree Code yes
JESD-609 Code e1
Series Spartan?-II
Published 2008
Packaging Tray
Operating Temperature -40°C~100°C TJ
Dimensions
Height Seated (Max) 2.6mm
Length 23mm
Width 23mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Number of Pins 456
Package / Case 456-BBGA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
