XC2S15-5TQ144I
RoHS
/
Package 144-LQFP
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Spartan?-II XC2S15 144-LQFP Surface Mount field programmable gate array 1.6mm 2.5V 263MHz 0.7ns
PDF
/
Buying Options
Total Price: USD $3.62
Unit Price: USD $3.624335
≥1 USD $3.624335
≥10 USD $3.419185
≥100 USD $3.225656
≥500 USD $3.043061
≥1000 USD $2.870813
Inventory: 1633
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 144-LQFP
Number of Pins 144
Technical
Operating Temperature -40°C~100°C TJ
Packaging Tray
Published 1999
Series Spartan?-II
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
ECCN Code EAR99
Subcategory Field Programmable Gate Arrays
Technology CMOS
Voltage - Supply 2.375V~2.625V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 225
Supply Voltage 2.5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number XC2S15
Pin Count 144
Number of Outputs 86
Qualification Status Not Qualified
Operating Supply Voltage 2.5V
Number of I/O 86
RAM Size 2kB
Clock Frequency 263MHz
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 432
Total RAM Bits 16384
Number of Gates 15000
Number of LABs/CLBs 96
Speed Grade 5
Combinatorial Delay of a CLB-Max 0.7 ns
Number of CLBs 96
Number of Logic Cells 432
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Width 20mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
