A14100A-1PG257M
RoHS
/
Package 257-BCPGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
CMOS 2012 Non-RoHS Compliant PIN/PEG field programmable gate array -55C~125C TC 2.6ns 125MHz 5V
PDF
/
Inventory: 4617
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 50.038mm
Length 50.038mm
Technical
Number of Registers 1153
Speed Grade 1
Number of Gates 10000
Number of Logic Elements/Cells 1377
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Turn On Delay Time 2.6 ns
Propagation Delay 2.6 ns
Number of I/O 228
Operating Supply Voltage 5V
Base Part Number A14100
Frequency 125MHz
Terminal Pitch 2.54mm
Supply Voltage 5V
Terminal Form PIN/PEG
Terminal Position PERPENDICULAR
Voltage - Supply 4.5V~5.5V
Technology CMOS
Number of Terminations 257
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series ACT? 3
Published 2012
Packaging Tray
Operating Temperature -55°C~125°C TC
Physical
Number of Pins 257
Package / Case 257-BCPGA
Mounting Type Through Hole
Mount Through Hole
