LC4256V-10F256BI
RoHS
/
Package FBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
MACROCELL CMOS EEPROM Non-RoHS Compliant field programmable gate array 105C 12.5mA 10ns 125MHz
PDF
/
Buying Options
Total Price: USD $22.18
Unit Price: USD $22.1848
≥1 USD $22.1848
Inventory: 916
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 17mm
Length 17mm
Height Seated (Max) 2.1mm
Technical
In-System Programmable YES
Number of Dedicated Inputs 4
JTAG BST YES
Number of Macro Cells 256
Output Function MACROCELL
Number of Logic Blocks (LABs) 16
Number of Programmable I/O 96
Number of Logic Elements/Cells 36
Programmable Logic Type EE PLD
Frequency (Max) 322MHz
Propagation Delay 10 ns
Memory Type EEPROM
Nominal Supply Current 12.5mA
Number of I/O 160
Operating Supply Current 12.5mA
Min Supply Voltage 3V
Max Supply Voltage 3.6V
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Pin Count 256
Time@Peak Reflow Temperature-Max (s) 30
Frequency 125MHz
Reach Compliance Code not_compliant
Terminal Pitch 1mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 225
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Programmable Logic Devices
HTS Code 8542.39.00.01
Additional Feature YES
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code EAR99
Number of Terminations 256
Moisture Sensitivity Level (MSL) 3
JESD-609 Code e0
Physical
Number of Pins 256
Package / Case FBGA
Mount Surface Mount
