LFE3-17EA-7LMG328I
RoHS
RoHS compliant
RoHS compliantPackage 328-LFBGA, CSBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
ECP3 LFE3-17 328-LFBGA CSBGA Tin/Silver/Copper (Sn/Ag/Cu) field programmable gate array 1.5mm 1.2V 420MHz 0.335ns
PDF
/
Inventory: 5873
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 328-LFBGA, CSBGA
Number of Pins 328
Technical
Operating Temperature -40°C~100°C TJ
Packaging Tray
Published 2012
Series ECP3
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 328
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Voltage - Supply 1.14V~1.26V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.2V
Terminal Pitch 0.5mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LFE3-17
Pin Count 328
Number of Outputs 116
Qualification Status Not Qualified
Operating Supply Voltage 1.2V
Memory Size 92kB
Operating Supply Current 29.8mA
Number of I/O 116
RAM Size 87.5kB
Clock Frequency 420MHz
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 17000
Total RAM Bits 716800
Number of LABs/CLBs 2125
Combinatorial Delay of a CLB-Max 0.335 ns
Dimensions
Height Seated (Max) 1.5mm
Length 10mm
Width 10mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
