EP4SE530H40C3ES
RoHS
/
Package 1517-BBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
STRATIX? IV E EP4SE530 1517-BBGA FCBGA TIN LEAD field programmable gate array 3.7mm 0.9V 717MHz 0C~85C TJ
PDF
/
Inventory: 9750
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 1517-BBGA, FCBGA
Surface Mount YES
Technical
Operating Temperature 0°C~85°C TJ
Packaging Tray
Series STRATIX? IV E
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN Code 3A001.A.7.A
Terminal Finish TIN LEAD
HTS Code 8542.39.00.01
Voltage - Supply 0.87V~0.93V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 220
Supply Voltage 0.9V
Terminal Pitch 1mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number EP4SE530
JESD-30 Code S-PBGA-B
Qualification Status Not Qualified
Number of I/O 976
Clock Frequency 717MHz
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 531200
Total RAM Bits 28033024
Number of LABs/CLBs 21248
Dimensions
Height Seated (Max) 3.7mm
Length 42.5mm
Width 42.5mm
Compliance
RoHS Status Non-RoHS Compliant
