EP2AGX125DF25C5NES

Intel
RoHS
/
Package 572-BGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description 124100CLBS Arria II GX EP2AGX125 572-BGA FCBGA field programmable gate array 2.2mm 0.9V 500MHz 0C~85C TJ
PDF
/
Inventory: 5725
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 572-BGA, FCBGA
Surface Mount YES

Technical

Operating Temperature 0°C~85°C TJ
Packaging Tray
Series Arria II GX
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 572
ECCN Code 3A991
HTS Code 8542.39.00.01
Voltage - Supply 0.87V~0.93V
Terminal Position BOTTOM
Terminal Form BALL
Supply Voltage 0.9V
Terminal Pitch 1mm
Reach Compliance Code compliant
Base Part Number EP2AGX125
JESD-30 Code S-PBGA-B572
Qualification Status Not Qualified
Number of I/O 260
Clock Frequency 500MHz
Organization 124100 CLBS
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 118143
Total RAM Bits 8315904
Number of LABs/CLBs 4964
Number of CLBs 124100

Dimensions

Height Seated (Max) 2.2mm
Length 25mm
Width 25mm
