EP1K100FC256-2N

Intel
RoHS
RoHS RoHS compliant
Package 256-BBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description ACEX-1K? EP1K100 256-BBGA Tin/Silver/Copper (Sn/Ag/Cu) field programmable gate array 2.1mm 2.52.5/3.3V 37.5MHz 0.5ns
PDF
/
Buying Options
Total Price: USD $30.41
Unit Price: USD $30.41425
≥1 USD $30.41425
≥10 USD $24.95555
≥100 USD $24.1756
≥500 USD $23.39565
≥1000 USD $22.6157
Inventory: 1152
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 17mm
Length 17mm
Height Seated (Max) 2.1mm

Technical

Output Function MIXED
Number of LABs/CLBs 624
Number of Gates 257000
Total RAM Bits 49152
Number of Logic Elements/Cells 4992
Programmable Logic Type LOADABLE PLD
Number of Inputs 186
Propagation Delay 0.5 ns
Clock Frequency 37.5MHz
Number of I/O 186
Power Supplies 2.52.5/3.3V
Qualification Status Not Qualified
Number of Outputs 186
JESD-30 Code S-PBGA-B256
Base Part Number EP1K100
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code compliant
Terminal Pitch 1mm
Supply Voltage 2.5V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 2.375V~2.625V
Technology CMOS
Subcategory Field Programmable Gate Arrays
HTS Code 8542.39.00.01
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code 3A991
Number of Terminations 256
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e1
Series ACEX-1K?
Packaging Tray
Operating Temperature 0°C~70°C TA

Physical

Surface Mount YES
Package / Case 256-BBGA
Mounting Type Surface Mount
