5SGXMA9K2H40C2N
RoHS
RoHS compliant
RoHS compliantPackage 1517-BBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
31700CLBS Stratix? V GX 5SGXMA9 1517-BBGA FCBGA field programmable gate array 3.9mm 0.91.52.52.5/31.2/3V 0C~85C TJ
PDF
/
Inventory: 2664
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 45mm
Length 45mm
Height Seated (Max) 3.9mm
Technical
Number of LABs/CLBs 317000
Total RAM Bits 53248000
Number of Logic Elements/Cells 840000
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Organization 31700 CLBS
Number of Inputs 696
Number of I/O 696
Power Supplies 0.91.52.52.5/31.2/3V
Qualification Status Not Qualified
Number of Outputs 696
JESD-30 Code S-PBGA-B1517
Base Part Number 5SGXMA9
Terminal Pitch 1mm
Supply Voltage 0.9V
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 0.87V~0.93V
Technology CMOS
Subcategory Field Programmable Gate Arrays
HTS Code 8542.39.00.01
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Stratix? V GX
Packaging Tray
Operating Temperature 0°C~85°C TJ
Physical
Surface Mount YES
Package / Case 1517-BBGA, FCBGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
