AT40K10-2BQC
RoHS
/
Package LQFP
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Contains Lead CMOS COMMERCIAL Non-RoHS Compliant field programmable gate array 70C 576B 2.2ns 166.67MHz
PDF
/
Buying Options
Total Price: USD $1.88
Unit Price: USD $1.87815
≥1 USD $1.87815
≥10 USD $1.5409
≥100 USD $1.49245
≥500 USD $1.44495
≥1000 USD $1.3965
Inventory: 8009
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case LQFP
Number of Pins 144
Technical
JESD-609 Code e0
Moisture Sensitivity Level (MSL) 3
Number of Terminations 144
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 225
Supply Voltage 5V
Terminal Pitch 0.5mm
Frequency 166.67MHz
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 144
Number of Outputs 192
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade COMMERCIAL
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Memory Size 576B
Number of I/O 114
RAM Size 576B
Frequency (Max) 100MHz
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Gates 20000
Number of Logic Blocks (LABs) 576
Combinatorial Delay of a CLB-Max 2.2 ns
Number of CLBs 576
Number of Logic Cells 576
Number of Equivalent Gates 10000
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Width 20mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
