EP4SGX530KH40I3N
RoHS
/
Package BGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
CMOS 2008 RoHS Compliant BALL FPGA 100C 3.3MB 600MHz 930mV
PDF
/
Buying Options
Total Price: USD $1431.88
Unit Price: USD $1431.88465
≥1 USD $1431.88465
Inventory: 25
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 42.5mm
Length 42.5mm
Height Seated (Max) 3.8mm
Technical
Number of Transceivers 36
Number of Logic Blocks (LABs) 21248
Number of Logic Elements/Cells 531200
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Data Rate 600 Mbps
Frequency (Max) 600MHz
RAM Size 3.3MB
Number of I/O 744
Memory Size 3.3MB
Min Supply Voltage 870mV
Max Supply Voltage 930mV
Power Supplies 0.91.2/31.52.5V
Operating Supply Voltage 900mV
Number of Outputs 744
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1mm
Supply Voltage 0.9V
Peak Reflow Temperature (Cel) 245
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Field Programmable Gate Arrays
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code 3A001.A.7.A
Moisture Sensitivity Level (MSL) 4
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2008
Physical
Number of Pins 1517
Package / Case BGA
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
