EP4S100G5H40I1
RoHS
/
Package BGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
CMOS 2008 Non-RoHS Compliant BALL FPGA 100C 3.3MB 600MHz 980mV
PDF
/
Buying Options
Total Price: USD $245679.62
Unit Price: USD $245679.615349
≥1 USD $245679.615349
≥10 USD $237601.175386
≥25 USD $235949.528688
≥50 USD $234309.363144
≥100 USD $229490.071638
≥500 USD $213082.70347
Inventory: 1669
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Package / Case BGA
Number of Pins 1517
Technical
Published 2008
JESD-609 Code e0
Pbfree Code no
Moisture Sensitivity Level (MSL) 4
ECCN Code 3A001.A.7.A
Terminal Finish Tin/Lead (Sn63Pb37)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 220
Supply Voltage 0.95V
Terminal Pitch 1mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Number of Outputs 654
Qualification Status Not Qualified
Operating Supply Voltage 950mV
Power Supplies 0.951.2/31.52.5V
Max Supply Voltage 980mV
Min Supply Voltage 920mV
Memory Size 3.3MB
Number of I/O 654
RAM Size 3.3MB
Frequency (Max) 600MHz
Data Rate 600 Mbps
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 531200
Number of Logic Blocks (LABs) 21248
Number of Transceivers 36
Dimensions
Height Seated (Max) 3.8mm
Length 42.5mm
Width 42.5mm
Compliance
RoHS Status Non-RoHS Compliant
